With
it's last design update in 2002, the YZFR1 for 2004 enters its 3rd generation
for its next 2 year reign.
Avaialble in team race colors Bue/White, plus the Red/Black shown, and
Silver & Black.
All
new 3rd Generation 1000cc YZF-R1 highlights the...
Yamaha 2004
Sportbike lineup
2004
YZF-R1
You're looking at what Yamaha says they're learned in 50 years of competition.
It begins with anew third-generation, 998cc, liquid-cooled, short-stroke,
20-valve, in-line four-cylinder engine designed to make 180 horsepower
power at a stratospheric 12,500 rpm. The shorter cylinder head is re-angled
farther forward to 40 degrees, far enough forward to allow the main
frame spars to go over the engine instead of around it.
That
straighter load path makes the Deltabox V frame massively strong,
even as it makes the bike narrow to better fit the rider. Together
with its light, strong and long Controlled Fill die cast truss
swingarm, all that power is deployed to the pavement with the
help of a fully adjustable piggyback shock absorber.
Titanium
exhaust with Yamaha's lightweight Exhaust Ultimate Powervalve
(EXUP) is routed under the seat for greater mass centralization.
56 degrees of cornering clearance is a good thing too.
New, five-spoke
wheels at both ends are light to spool up fast. Radial-mount forged
calipers and 320mm discs provide outstanding braking performance
for bending controllably into tight chicanes at the end of long,
sixth-gear straights. |
 |
|
2004
YZF-R1 Specifications
Engine Type
Type 998cc, liquid-cooled, 20-valve, DOHC, in-line four-cylinder
Bore x Stroke 77 x 53.6mm
Compression Ratio 12.1:1
Carburetion Fuel injection, dual-valve throttle bodies with motor-driven
secondary valves
Ignition Digital TCI
Transmission 6-speed w/multi-plate clutch
Final Drive #530 O-ring chain
Other
Primary Reduction Ratio 65/43 (1.512)
Secondary Reduction Ratio 45/17 (2.647)
Color Team Yamaha Blue/White; Liquid Silver/Cerulean Silver; Shift
Red
Warranty 1 Year (Limited Factory Warranty)
|
Chassis
Suspension/Front 43mm inverted telescopic fork w/adjustable preload,
compression and rebound damping; 4.7" travel
Suspension/Rear Single shock w/piggyback reservoir and adjustable
preload, compression and rebound damping; 5.1" travel
Brakes/Front Dual 320mm discs; radial-mount forged 4-piston calipers
Brakes/Rear 220mm disc w/single-piston pin-slide caliper
Tires/Front 120/70-ZR17
Tires/Rear 190-50-ZR17
Dimensions
Length 81.3"
Width 28.3"
Height 43.5"
Seat Height 32.8"
Wheelbase 54.9"
Rake (Caster Angle) 24.0°
Trail 3.8"
Fuel Capacity 4.85 gallons
Dry Weight 379 lbs.
|
2004
YZF-R6
Something old, something new, something blue? Newly redesigned for 2003
from the ground up, the 2004 YZF-R6 just gets minor revisions midway thru
its 2-year design cycle. Still, if you never let the YZF-R6's tachometer
needle roam into the second half of its arc, you might never know what's
lurking there waiting to be unleashed. And... here's what's new for 2004.
An ingenious suction-piston
fuel injection system (re-mapped for '04), among other things, endows
it with amazingly goodroad manners at low and medium engine speeds.
But we had a higher calling in mind for the little beast that won the
AMA Supersport Class Championship** right out of the gate as well as
Cycle World, Sport Rider and Motorcycle Online 600 comparisons.*
A 15,500 rpm redline.
Redesigned exhaust canister providing improved exhaust flow for 2004.
This one is pure sportbike, designed from the asphalt up to achieve
a delicate, sublime blend of handling and horsepower, finesse and feel,
hyperactive agility and laser-beam predictability.
Absolute leading-edge
technology takes tangible form in the R6's light and rigid DeltaBox
III frame - an almost seamless pieceof alloy artisanship that allowed
the engineers to put strength - and the revvy 4-cylinder - exactly where
they belong. From there, all sorts of good things flow.
2003
YZF-R6 Specifications
Available
from October 2003 •
MSRP TBA
Engine Type
600cc, Liquid cooled, 4-stroke, forward inclined inline 4 cylinder,
DOHC, 16 valves Bore x Stroke 65.5 x 44.5mm Compression Ratio 12.4 1
Carburetion Fuel Injection Ignition Digital DC-CDI Transmission 6-speed
w/multi-plate clutch Final Drive #530O-ring chain
Chassis
Suspension
Front 43mm inverted telescopic fork w/adjustable preload, compression
and rebound damping; 4.7" travel Suspension/Rear Single shock w/piggyback
reservoir and adjustable preload, compression and rebound damping; 4.7"
travel Brakes/Front Dual 298mm floating discs w/4-piston calipers Brakes/Rear
220mm disc w/ single-piston caliper Tires/Front 120/60-ZR17 Tires/Rear
180-55-ZR17 Dimensions Length 79.7" Width 27.2" Height 42.9"
Seat Height 32.3" Wheelbase 54.3" Rake (Caster Angle) 24.0°
Trail 3.4" Fuel Capacity 4.5 gallons Oil Capacity (with oil filter
change) 2.85 Qt. Dry Weight 357 lbs.
Other
Primary Reduction Ratio 86/44 (1.955) Secondary Reduction Ratio 48/16
(3.000) Gear Ratio - 1st Gear 37/13 (2.846) Gear Ratio - 2nd Gear 28/18
(1.556) Gear Ratio - 3rd Gear 28/18 (1.556) Gear Ratio - 4th Gear 32/24
(1.333) Gear Ratio - 5th Gear 25/21 (1.190) Gear Ratio - 6th Gear 26/24
(1.083) Color Team Yamaha Blue/White; Liquid Silver w/ Flames; Rapid
Red Warranty 1 Year (Limited Factory Warranty)
|
